SKIPPER ETNSTC combo steel tank

Part Number: ETNSTC

The ETNSTC is a combo steel tank designed for SKIPPER echo sounders. It has a flange installed inside in order to fit various transducers and sensors.

Read product description

Where to buy

Features

Combo steel tank
DNV approval as standard
CCS available on request
Other approvals on request

Product:	Combo steel tank
Part number:	ETNSTC
Opening diameter:	100 mm
Hull type:	All steel hulls
Tank material:	Steel
Flange material:	N/A
Approval with part number:	ETNST Standard with DNV approval ETNST-ABS With ABS approval ETNST-BV With BV approval ETNST-LR With LR approval ETNST-RINA With RINA approval
Mandatory accessories:	A-PACKING Special packing materials
Weight:	35 kgs
Designed for:	DL1ST-SA DL2ST-SA EML224ST-SD ETN050T 50 kHz transducer with 25 m cable ETN050XT 50 kHz transducer with 40 m cable ETN200T 200 kHz transducer with 25 m cable ETN200XT 200 kHz transducer with 40 m cable ETN200ST 200 kHz transducer with 25 m cable ETN200SXT 200 kHz transducer with 40 m cable ETS50200T-SA 50/200 kHz dual transducer with 25 m cable ETS50200XT-SA 50/200 kHz dual transducer with 50 m cable
Service:	Available in most major harbours, world-wide through extensive dealer network

Documentation type

Date

Type

Name

Size

Download

29.06.26

Manual

Manual DM-BETNSTC-SA ComboTank

1115 KB

31.08.26

Technical

Illustrated parts list_Tanks (DOC1734531_rev02)

1255 KB

Software and certificates will soon be available for download in Jotron Product Passport. Until then, you can download them here: Certificates, Software.
