SKIPPER 200 kHz transducer
Part Number: Multiple options
SKIPPER 200 kHz transducers are designed and approved with all SKIPPER Echo Sounders. Normal depth range for the 200 kHz transducers are approx. 200-400 m depending on water/bottom quality.
Features
- 200 kHz navigational transducer
- Different adaptors to different bottom arrangement
- Optional cable length (25 and 40 m)
| Product: | 200 kHz transducer |
| Part number: | Multipe options |
| Frequency: | 200 kHz |
| Range: |
|
| Material: | Rubber |
| Weight: | 10 kgs |
| Beam: 6 degrees |
|
| Beam 11 degrees: |
|
| Diameter 14 cm: |
|
| Diameter 10 cm: |
|
| Classifications: |
|
Available in these variants:
| ETN200T (Cable length 25) | for mounting in ETNST and ETNSTC |
| ETN200XT (Cable length 40) | for mounting in ETNST and ETNSTC |
| ETN200ST (Cable length 25) | for mounting in ETNST and ETNSTC |
| ETN200STX (Cable length 40) | for mounting in ETNST and ETNSTC |
| ETN200SG (Cable length 25) | for mounting in:
|
| ETN200SXG (Cable length 40) | for mounting in:
|
| ETN200ST-ICE (Cable length 25) | for mounting in ETNSTCI Ice protected tank |
| ETN200TSXT-ICE (Cable length 40) | for mounting in ETNSTCI Ice protected tank |
| ETN200STA (Cable length 25) | for mounting in ETNALC Aluminium tank |
| ETN200SXTA (Cable length 40) | for mounting in ETNALC Aluminium tank |
| ETN200FS(Cable length 25) | for mounting in ETNSLJB |
| ETN200FSX (Cable length 40) | for mounting in ETNSLJB |
Documentation type
Date
Type
Name
Size
Download
30.08.26
Dismantling and recycling
Disposal SKIPPER Sensors
288 KB
29.06.26
Guide
Guide Echo Sounder setup and options 144
535 KB
20.08.26
Technical
Data bulletin_Changing transducer with the help of a diver
390 KB
20.08.26
Technical
Data bulletin_Statement Ice pressure
133 KB
20.08.26
Technical
Data bulletin_Statement, end of Ice Plates
253 KB
20.08.26
Technical
Illustrated parts list_Navigational transducers (DOC1733012_rev02)
1552 KB
Software and certificates will soon be available for download in Jotron Product Passport. Until then, you can download them here: Certificates, Software.
